Analog Devices MAX30001 Manual page 25

MAX30001 Evaluation System
MAX30001 EV Kit Bill of Materials (BOM)
ITEM REF_DES
1V8, 3V3, GND1, GND2, J_CSB,
1 J_SDI, J_SDO, J_SYS, BB_SEL,
J_INTB, J_SCLK, J_INT2B, J_EXT_PWR
BB, BIN, BIP, CSB, SDI, SDO, VBG, VCM,
AGND, AOUT, DRVN, DRVP, ECGN, ECGP,
2
FCLK, INTB, SCLK, VREF, AGND1-AGND4,
INT2B, RBIAS, FTHR_GND, BUFF1_OUT
3 AVDD, DVDD, OVDD, EXT_PWR
RN, RP, P_UP, BP_BN, DN_BN, DP_BP, EN_BN,
EP_BP, EP_EN, J_BIN, J_BIP, J_AVDD, J_DRVN,
4 J_DRVP, J_DVDD, J_ECGN, J_ECGP, J_OVDD,
P_DOWN, J_RBIAS, XTL_PWR, BUFF1_IN,
EN_UNBAL, EP_UNBAL, ONBRD_FCLK
5 C1-C3, C30
6 C4
7 C5-C7, C16-C21, C23
8 C9, C10, C14, C15
9 C11-C13, C22
10 C27, C31
11 C32
C_BB, C_BIN, C_BIP, C_DRVN, C_DRVP,
12
C_ECGN, C_ECGP
13 D1
14 J8
15 J9
16 R1, R31
17 R2, R3
18 R4, R10
19 R5, R6
20 R7
21 R9, R11, R36
22 R12
23 R13, R18, R19, R28
24 R14
25 R20, R25
26 R26, R27, R29, R30
27 U1
28 U2
29 U3
30 U4
31 U5
32 PCB
33 C8, C24-C26, C28, C29
34 R8, R15-R17
TOTAL
www.analog.com
DNI/DNP QTY MFG PART #
- 13 PCC03SAAN
- 26 5011
- 4 5010
- 25 5-146280-2
- 4 C0805C473J3GAC
- 1 UMK107AB7105KA
- 10 GRM188R61E106MA73
- 4 C3216X7R1H335M160AC
- 4 C1608X7R1E104K080AA
GRM31CR72A225KA73;
- 2
KRM31KR72A225KH01
- 1 C0603C102J5GAC; 06035A102JAT2A
- 7 41828-50
- 1 LTST-C194KGKT
- 1 PPPC161LFBN-RC
- 1 PPPC121LFBN-RC
- 2 ERA-6ARW513
- 2 CRCW06031001FK; ERJ-3EKF1001V
- 2 3296Y-202LF
- 2 CRCW06031K33FK
- 1 3296Y-1-103LF
- 3 CRCW06031003FK; ERJ-3EKF1003
- 1 RN73C1J324KB; 4-1879135-8
- 4 RG1608P-101-B-T5; ERA-3YEB101V
- 1 RG1608P-471-B-T5
- 2 ERA-3ARB103
CRCW06030000ZS; MCR03EZPJ000;
- 4
ERJ-3GEY0R00
- 1 MAX30001CWV+
- 1 MAX1806EUA18+
- 1 MAX8512EXK
- 1 MAX44263AXA+
- 1 SG-3030-JF-32.768000KHZ-B
- 1 MAX
DNP 0 N/A
DNP 0 CRCW06031003FK; ERJ-3EKF1003
134
MANUFACTURER VALUE
CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY;
SULLINS PCC03SAAN
STRAIGHT THROUGH; 3PINS; -65 DEGC TO +125 DEGC
TEST POINT; PIN DIA=0.125IN; TOTAL LENGTH=0.445IN;
KEYSTONE N/A BOARD HOLE=0.063IN; BLACK;
PHOSPHOR BRONZE WIRE SILVER PLATE FINISH;
KEYSTONE N/A TESTPOINT WITH 1.80MM HOLE DIA, RED, MULTIPURPOSE;
CONNECTOR; MALE; THROUGH HOLE; HEADER ASSEMBLY;
TE CONNECTIVITY 5-146280-2 MOD II; BREAKWAY; SINGLE ROW; HIGH TEMPERATURE;
VERTICAL W/ 0.025 SQ POST; 0.100 C; STRAIGHT; 2PINS
CAPACITOR; SMT (0805); CERAMIC CHIP; 0.047UF; 25V;
KEMET 0.047UF
TOL=5%; TG=-55 DEGC TO +125 DEGC; TC=C0G
CAPACITOR; SMT (0603); CERAMIC CHIP; 1UF; 50V;
TAIYO YUDEN 1UF
TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R
CAPACITOR; SMT (0603); CERAMIC CHIP; 10UF; 25V;
MURATA 10UF
TOL=20%; TG=-55 DEGC TO +85 DEGC; TC=X5R; GRM SERIES; MURATA
CAPACITOR; SMT (1206); CERAMIC CHIP; 3.3UF; 50V;
TDK 3.3UF
TOL=20%; MODEL=C SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R
CAPACITOR; SMT (0603); CERAMIC CHIP; 0.1UF; 25V;
TDK 0.1UF
TOL=10%; MODEL=C SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R
CAPACITOR; SMT (1206); CERAMIC CHIP; 2.2UF; 100V;
MURATA 2.2UF
TOL=10%; MODEL=GRM SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R
CAPACITOR; SMT; 0603; CERAMIC; 1000pF; 50V; 5%;
KEMET/AVX/MURATA 1000PF
C0G; -55degC to +125degC
CONNECTOR; FEMALE; THROUGH HOLE; JACK; PCB; 1.5MM;
PLASTICS ONE 41828-50
TOUCHPROOF WAVE SOLDER VERSION WITH STAMPING; RIGHT ANGLE; 3PINS
DIODE; LED; SMD CHIP LED; WATER CLEAR LENS;
LITE-ON ELECTRONICS INC LTST-C194KGKT
AlInGaP GREEN; GREEN; SMT (0603); VF=2.1V; IF=0.02A
CONNECTOR; FEMALE; THROUGH HOLE; LFB SERIES;
SULLINS ELECTRONICS CORP. PPPC161LFBN-RC
2.54MM CONTACT CENTER; STRAIGHT; 16PINS
CONNECTOR; FEMALE; THROUGH HOLE;
SULLINS ELECTRONICS CORP PPPC121LFBN-RC
HEADER FEMALE; STRAIGHT; 12PINS
PANASONIC 51K RESISTOR; 0805; 51K OHM; 0.05%; 10PPM; 0.125W; THIN FILM
VISHAY DALE; PANASONIC 1K RESISTOR; 0603; 1K; 1%; 100PPM; 0.10W; THICK FILM
RESISTOR; THROUGH HOLE-RADIAL LEAD;
BOURNS 2K
3296Y SERIES; 2K OHM; 10%; 100PPM; 0.5W
VISHAY DALE 1.33K RESISTOR; 0603; 1.33K; 1%; 100PPM; 0.10W; THICK FILM
RESISTOR; THROUGH-HOLE; 10K OHM; 10%;
BOURNS 10K
100PPM; 0.5W; MOLDER CERAMIC OVER METAL FILM
VISHAY DALE/PANASONIC 100K RESISTOR; 0603; 100K; 1%; 100PPM; 0.10W; THICK FILM
TE CONNECTIVITY 324K RESISTOR; 0603; 324K OHM; 0.1%; 10PPM; 0.063W; THIN FILM
SUSUMU CO LTD./PANASONIC 100 RESISTOR; 0603; 100 OHM; 0.1%; 25PPM; 0.1W; THICK FILM
SUSUMU CO LTD. 470 RESISTOR; 0603; 470 OHM; 0.1%; 25PPM; 0.10W; THICK FILM
PANASONIC 10K RESISTOR; 0603; 10K OHM; 0.1%; 10PPM; 0.1W; THIN FILM
VISHAY DALE/ROHM/
0 RESISTOR; 0603; 0 OHM; 0%; JUMPER; 0.10W; THICK FILM
PANASONIC
EVKIT PART-IC; MAX30001; ULTRA-LOW POWER;
ANALOG DEVICES
SINGLE-CHANNEL INTEGRATED BIOPOTENTIAL
MAX30001CWV+
AND BIOIMPEDANCE AFE; PACKAGE OUTLINE: 21-100074;
PACKAGE CODE: W302L2+1; WLP30
ANALOG DEVICES
MAX1806EUA18+ IC; VREG; LOW-VOLTAGE LINEAR REGULATOR; UMAX8-EP
ANALOG DEVICES
MAX8512EXK IC, VREG, Ultra-Low-Noise, High PSRR, Adjustable Vout, SC70-5
ANALOG DEVICES
IC; OPAMP; 1.8V; 15MHZ LOW-OFFSET; LOW-POWER;
MAX44263AXA+
RAIL-TO-RAIL I/O DUAL OPERATIONAL AMPLIFIER; SC70-8
EPSON 32.768KHZ OSCILLATOR; SMT; 32.768KHZ;
ANALOG DEVICES
PCB PCB:MAX
N/A OPEN PACKAGE OUTLINE 0603 NON-POLAR CAPACITOR
VISHAY DALE/PANASONIC 100K RESISTOR; 0603; 100K; 1%; 100PPM; 0.10W; THICK FILM
Evaluates: MAX30001
MAX30002
DESCRIPTION
Analog Devices │ 25
