MAX30001 Evaluation System
Table 1. Description Of Jumpers (continued)
JUMPER SHUNT POSITION
1V8
3V3
J_AVDD
J_DVDD
J_OVDD
XTL_PWR
ONBRD_FCLK
GND1 1-2**
GND2 1-2**
J_EXT_PWR
J_SYS 1-2**
J_INTB 1-2**
J_INT2B 1-2**
J_SDO 1-2**
J_SDI 1-2**
J_SCLK 1-2**
J_CSB 1-2**
P_UP
P_DWN
* Default shunt position
** Default shunt position, do not use alternate position
www.analog.com
1-2 Supply 1.8V to J_AVDD and J_DVDD from the MAX32630FTHR.
2-3* Supply an adjustable voltage to J_AVDD and J_DVDD from an LDO (U2).
1-2 Supply 3.3V to J_OVDD and OVDDX from the MAX32630FTHR.
2-3* Supply an adjustable voltage to J_OVDD and OVDDX from an LDO (U3).
1-2* Connect AVDD to pin 2 of jumper 1V8.
1-2* Connect DVDD to pin 2 of Jumper 1V8.
1-2* Connect OVDD to pin 2 of jumper 3V3.
1-2* Power the onboard crystal from OVDDX.
1-2* Connect the onboard crystal to FCLK.
Connect GND of the MAX32630FTHR to AGND1.
Connect GND of the MAX32630FTHR to AGND2.
1-2 Connect an external supply to the 5V rail.
2-3 Do not use.
Connect SYS on the MAX32630FTHR to the 5V rail.
Connect INTB to the MAX32630FTHR.
Connect INT2B to the MAX32630FTHR.
Connect SDO to MISO of the MAX32630FTHR.
Connect SDI to MOSI of the MAX32630FTHR.
Connect SCLK to SCLK of the MAX32630FTHR.
Connect CSB to the MAX32630FTHR.
1-2 Connect R8-11 to OVDDX.
1-2* Connect R15-17 to GND.
