User Guide
MODULE OPERATION
Table 24. Error Code Messages and Troubleshooting
Index Error Code Message
1 ADC Error during self-test
2 ADC Error during measurement
3 **ERROR: -113, "Undefined header"
4 **ERROR: -224, "Illegal parameter value"
5 **ERROR: -101, "Invalid character"
6 **ERROR: -200, "Execution error"
analog.com
Description
The ADMX3652 performs a self-test of ADC at
startup and periodically during measurements.
When an error is detected, the device outputs a
message that starts with "Adc...".
The signal chain of the channel is not typical
for ADC conversion. When an error is detected,
the device outputs messages beginning with "ADC
encounter ADC_ERROR...".
This command is not supported by the ADMX3652. Change the command to a supported command and
The parameter does not comply with the command. Check the parameter and retry.
The command includes unrecognized characters.
This command includes execution failure.
EVAL-ADMX3652
Troubleshooting
Hardware has issue. Contact Analog Devices Sales
for further assistance.
Hardware has issue. Contact Analog Devices Sales
for further assistance.
retry.
Check the command and retry.
Check if the baud rate or NPLC in the configuration
command follows the rule in Table 10.
