User Guide
MODULE OPERATION
10 seconds on a hot start. After the self test process completes, the
ADMX3652 outputs a DAQ is ready to use message.
IEEE 488.2 Common Commands
The following tables detail the IEEE 488.2 common commands
(*RST and *IDN?).
Table 1. Command, *RST
Syntax
*RST
Function
Resets the
ADMX3652
Explanations
After this command is received, the ADMX3652 sets
all parameters to the factory default values, except the
calibration parameters and baud rate setting. Then, the
ADMX3652 restarts to initiate the device.
Example
*RST
Table 2. Command, *IDN?
Syntax
*IDN?
Function
Queries the ID character string of the instrument.
Explanations
The query returns two character segments separated by
commas: manufacturer, internal device name.
Example
*IDN? returns ADMX3652.
Configuration Commands
The following tables detail the configuration com-
mands (SYSTem:PLC:SET, CONFigure:VOLTage:DC, CONFig-
ure:VOLTage:DC?, CONFigure:VOLTage:DC:NPLCycles, CON-
Figure:VOLTage:DC:NPLCycles?, SYSTem:BAUDRATE:SET,
SYSTem:BAUDRATE:SET?, CONFIGURE:INFormation?, and
CONFigure:CONTINUOUS:READ).
Table 3. Command, SYSTem:PLC:SET
Syntax
SYSTem:PLC:SET {50|60}
Function
Sets the power line frequency as 50 Hz or 60 Hz.
Explanations
Users can use this function to set power line frequency to
reject the power line noise when NPLC is set to be greater
than or equal to 1.
Example
SYSTem:PLC:SET 50 sets power line frequency as 50 Hz.
Table 4. Command, CONFigure:VOLTage:DC
Syntax
CONFigure:VOLTage:DC {1|2}, {0.2|2|20|AUTO}
Function
Sets the measuring voltage range of Channel 1 or Channel
2.
Explanations
Users can use this function to set Channel x to its meas-
urement range option: 0.2 V, 2 V, 20 V, or auto range. Use
{1|2} to specify the channel and {0.2|2|20} to specify the
range. Channel 1 and Channel 2 must be set separately
with two commands.
Example
CONFigure:VOLTage:DC 1,20 sets the measurement
range of Channel 1 to ±20 V.
analog.com
to the factory default states.
EVAL-ADMX3652
Table 5. Command, CONFigure:VOLTage:DC?
Syntax
CONFigure:VOLTage:DC? {1|2}
Function
Queries the measuring voltage range of Channel 1 or
Channel 2.
Explanations
Users can use this function to query the measuring voltage
range of Channel x. Use {1|2} to specify the channel.
Channel 1 and Channel 2 must be queried separately with
two commands.
Example
CONFigure:VOLTage:DC? 1 returns the measuring volt-
age range of Channel 1.
Table 6. Command, CONFigure:VOLTage:DC:NPLCycles
Syntax
CONFigure:VOLTage:DC:NPLCycles{1|2}, {0.05|0.1|
0.25|0.5|1|10|100}
Function
Sets the aperture time of Channel 1 or Channel 2.
Explanations
Users can use this function to set the aperture time of
Channel x according to the PLC. The higher the aperture
time results in a higher measurement resolution. The aper-
ture time is calculated as NPLC times the cycle time of
the power line frequency. The aperture time can be set
differently for each channel.
Example
CONFigure:VOLTage:DC:NPLCycles1,10 sets the Chan-
nel 1 aperture time to 400 ms when the power line frequen-
cy is 50 Hz and auto-zero is enabled.
Table 7. Command, CONFigure:VOLTage:DC:NPLCycles?
Syntax
CONFigure:VOLTage:DC:NPLCycles? {1|2}
Function
Queries the NPLC setting of Channel 1 or Channel 2.
Explanations
User can use this function to query the NPLC setting of
Channel x according to PLC. Use {1|2} to specify the chan-
nel. Channel 1 and Channel 2 must be queried separately
with two commands.
Example
CONFigure:VOLTage:DC:NPLCycles? 1 returns the
NPLC setting of Channel 1.
Table 8. Command, SYSTem:BAUDRATE:SET
Syntax
SYSTem:BAUDRATE:SET {9600|14400|19200|38400|
57600|115200|230400|460800}
Function
Sets the baud rate of the UART communication.
Explanations
User can use this function to set the baud rate of the
UART communication interface. The new baud rate acti-
vates immediately after this command is transmitted. Each
baud rate matches its minimum supported NPLC setting as
suggested in
Example
SYSTem:BAUDRATE:SET 460800 sets the baud rate to
460,800 bps.
1
This command is valid in the firmware version of Revision 4.5.1 and afterward.
Table 9. Command, SYSTem:BAUDRATE:SET?
Syntax
SYSTem:BAUDRATE:SET?
Function
Queries the current baud rate of the UART communication.
1
Table
10, which must be followed.
Rev. B | 14 of 22
