KIT COMPONENTS

One (1) Speedometer Panel One (1) Clock
One (1) Tachometer Panel One (1) Fuel Level & Voltmeter Panel
One (1) Oil Pressure & Water Temperature Panel
Nine (9) Smoked Acrylic Lens & mounting plates
One (1) Temperature Sending Unit (S8013) 1/8" NPT, 0-255 Deg., 1/2" NPT Bushing
One (1) Pressure Sending Unit (S8434) 1/8" NPT, 0-100 PSI Oil Pressure
One (1) Universal GPS Speedometer Sensor (S9021)
One (1) Mounting Kit (Next Page)
Speedo Hardware kit
Two (2) #6 x 2" Recessed Phillips head screws Two (2) #6 x 1" Nylon spacers
Two (2) #6 x ¼" Nylon spacers Four (4) #6 Nylock nuts
Four (4) #4 x 1" Recessed Phillips head screws Four (4) #6 x 3/8 Nylon spacers
Four (4) #4 Nylock nuts Four (4) #6 Nylon Washers
Tachometer Hardware kit
Two (2) #6 x 2" Recessed Phillips head screws Two (2) #6 x 3/4" Nylon spacers
Four (4) #6 Nylock nuts Six (6) #6 x 3/8 Nylon spacers
Four (4) #4 x 1" Recessed Phillips head screws Six (6)) #6 Nylon Washers
Four (4) #4 Nylock nuts
