AJAX KeyPad Plus User Manual page 4

KeyPad Plus supports code types as follows:
Keypad code — general code set up for the keypad. When used, all events are
delivered to Ajax apps on behalf of the keypad.
User code — personal code set up for a user connected to the hub. When used,
all events are delivered to Ajax apps on behalf of the user.
Keypad access code — set up for a person who is not registered in the system.
When used, events are delivered to Ajax apps with a name associated with this
code.
RRU code is an access code for the rapid response units (RRU) activated after
the alarm and valid for a specified period. When the code is activated and used,
events are delivered to Ajax apps with a title associated with this code.
The number of personal, access, and RRU codes depends on the hub model.
Access codes are not supported by the
Before entering a code or using Tag/Pass, you should activate ("wake up") the
KeyPad Plus by sliding your hand over the touch panel from top to bottom. When it is
activated, the button backlight is enabled, and the keypad beeps.
Auto-wake on Delay when Entering function allows automatically activating the keypad when
Delay When Entering
firmware version 5.60.7.0 or higher and hubs with
The KeyPad Plus is equipped with LED indicators that show the current security
mode and keypad malfunctions (if any). The security status is displayed only when
the keypad is active (the device backlight is on).
Hub (2G) Jeweller
is set up. This function is supported by KeyPad Plus Jeweller with
control panel.
OS Malevich 2.19 or higher.
