AJAX KeyPad Plus User Manual page 28

You can activate the keypad by swiping your hand over the touch panel from top to
bottom. When activated, the backlight on the keypad will turn on and a beep will
sound (if enabled).
Event
There is no connection to the hub or radio signal
range extender
KeyPad Plus body is open (SmartBracket mount is
removed)
Touch button pressed
The system is armed
The system is disarmed
An incorrect code was entered or there was an
attempt to change security mode by an
unconnected or deactivated pass/tag
The security mode cannot be activated (for
example, a window is open and the System
integrity check is enabled)
The hub does not respond to the command —
there is no connection
The keypad is locked due to a wrong code attempt
or attempt to use an unauthorised pass/tag
The batteries are low
The system requires to confirm authorization with
a password after access devices' confirmation.
Available if the Authorization confirmation with a
passcode feature is activated
Indication
LED X blinks
LED X blinks briefly once
Short beep, the current system security status LED
blinks once. The volume depends on the keypad
settings
Short beep, Armed or Night Mode LED lights up
Two short beeps, the Disarmed LED lights up
Long beep, digital unit LED backlight blinks 3 times
Long beep, the current security status LED blinks 3
times
Long beep, X (Malfunction) LED lights up
Long beep, during which the security status LEDs
and keypad backlight blink 3 times
After changing the security mode, the X LED lights
up. The touch buttons are locked for this
time.When you try to turn on the keypad with
discharged batteries, it emits a long beep, the
LED smoothly lights up and goes off, then the
keypad turns off
How to replace batteries in KeyPad
Plus
The current security status LED blinks during the
set time for confirmation
X
