Specifications

Amplifier Section

THD (Total Harmonic
Distortion)
Input Sensitivity and
Impedance
Output Level and
Impedance
Phono Overload
Frequency Response
Tone Control
Signal to Noise Ratio

Video Section

Input Sensitivity/Output
Level and Impedance
Component Video
Frequency Response

Tuner Section

■ FM
Tuning Frequency Range
North American:
European and Asian: 87.50 MHz– 108.00 MHz, RDS
■ AM
Tuning Frequency Range
North American:
European and Asian: 522 kHz–1611 kHz
Preset Channel

■ Digital Tuner

North American:
132
0.05% (Power Rated)
200 mV/ 47 kΩ (LINE)
2.5 mV/47 kΩ (PHONO MM)
200 mV/ 470 Ω (REC OUT)
70 mV (MM 1 kHz, 0.5%)
5 Hz–100 kHz/ +1 dB–3 dB (Direct mode)
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
1 Vp-p /75 Ω
(Component and S-Video Y)
0.7 Vp-p /75 Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
5 Hz – 100 MHz, –3 dB
87.5 MHz– 107.9 MHz
530 kHz–1710 kHz
40
XM, SIRIUS, HD RADIO
General
Power Supply
North American: AC 120 V, 60 Hz
European and Asian: AC 220-240 V, 50 Hz/60 Hz
Power Consumption
North American: 1.1 A
European and Asian: 85 W
Dimensions
× × ×
(W H D) 435
17-1/8"
Weight 13.5 kg
29.8 lbs.
■ Video Input
HDMI IN 1, IN 2, IN 3, IN 4
Component IN 1 (DVD), IN 2, IN 3
S-Video DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX 1, AUX 2
Composite DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX 1, AUX 2

■ Video Output

HDMI MAIN OUT, SUB OUT
Component MONITOR OUT 1,
MONITOR OUT 2/ZONE 2 OUT
S-Video VCR/DVR OUT, MONITOR OUT
Composite VCR/DVR OUT, MONITOR OUT,
ZONE 2 OUT

■ Audio Inputs

Digital Inputs OPTICAL: 2 (Rear), 1 (Front)
COAXIAL: 3 (Rear)
Analog Inputs MULTI CH (FRONT, CENTER,
SUBWOOFER, SURR, SURR BACK),
DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX 1, TAPE, CD, PHONO, AUX 2
Balance Inputs BALANCE L, BALANCE R
Multichannel Inputs 7.1

■ Audio Outputs

Digital Output OPTICAL: 1 (Rear)
Analog Outputs VCR/DVR OUT, TAPE OUT, PRE OUT
(FRONT, CENTER, SUBWOOFER,
SURR, SURR BACK)
Z2 PREOUT, Z3 PREOUT
Balance Pre Outputs FL, FR, C, SL, SR, SBL, SBR, SW
Multichannel Pre
Outputs 7
Subwoofer Pre Outputs 1
Phones 1
■ Control Terminal
MIC Yes
Ether 1(e-control)
RS232 1
IR Input/Output 2/1
12 V Trigger Out 3
Specifications and features are subject to change without
notice.
×
194 444.5 mm
× ×
7-5/8" 17-1/2"
