When this Mixer is used in a DO8 Application the following Instructions apply:
Introduction
This Inta Thermostatic Mixer has been specifically designed and manufactured to meet the
requirements of BS 7942: 2000 and NHS D08. The product has been independently tested
and approved as a TYPE 3 valve under the TMV3 scheme.
Technical Specification
Outlet Temp Adjustment Range
Temperature Stability
Max. Hot Inlet Temp
Inlet Temperature Range
0.5˚C to 20˚C
Max. Working Pressure
Min. Working Pressure
D08 Working Pressure Ranges
Min. Temp Differential (Mix to Hot) for fail-safe
Max. Pressure inlet Differential
Application
This thermostatic mixer has been independently tested by WRc and certified as meeting the
requirements of the NHS D08 specification under the TMV3 Scheme as being suitable for use
on the following;
Code
HP-W
Installation
IMPORTANT – The following instructions must be read prior to the installation of any thermostatic
mixing valve.
The installer should also be aware of his responsibility and duty of care to ensure that all aspects
of the installation comply with all current regulations and legislations.
It has been brought to our attention that flushing water systems using certain chemicals may affect
the workings of the valve, which may adversely affect its performance.
We recommend that following system flushing with chemicals, mixers are checked for correct
operation.
1. It is essential that, before installing a thermostatic mixing valve, the supply conditions of the
system to which the valve is intended to be fitted are checked to confirm compliance with the
parameters as quoted within the Technical Specification above and conditions on which the
approval is granted i.e. verify supply temperatures, supply pressures, risk assessments etc.
© Intatec Ltd 2016
30˚C to 50˚C
+ 2˚C
85˚C
55˚C to 65˚C
Cold Supply
10 bar
1.0 bar
1.0 to 5.0 bar High Pressure
10˚C
5:1
Application
Basin
16
Hot Supply
Static
Dynamic
Range
High Pressure
