Showven SPARKULAR WAVERFALL User Manual page 9

Channel Function
CH1 Manual Angle setup
Manual Nozzle
CH2
Waving Speed setup
CH3 Firing ON/OFF
CH4
CH5 Preset sequence setup
CH6 Mode setup
Channel 1 (CH1): Manual Angle Setup
SPARKUALR waverFALL output nozzle can be stayed at any angle between -90° to 90°, below is
a list of typical angles used in our preset sequence with related DMX value.
Angle No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Angle Definition
SPARKUALR waverFALL with waving output nozzle firing between -90° to +90°, we devided
180 degree into 13 firing directions as below (audience side view).
0~255: angle change from -90° to 90°
128: straight upward (0°)
0 and 255: Max Speed
1~254: Speed increase
0~15: Firing OFF
16~90: Firing height low
91~170: Firing height medium
171~255: Firing height high
Maxi. Single firing duration is 60s
n/a Reserved
0-2: no preset sequence
3-255: preset sequence
DMX value = 2 + Sequence No.*2.55 (ROUND OFF)
0~49: Heating Up OFF (Emergency Stop)
50~200: Heating Up ON
201~255: Heating Up OFF (Emergency Stop)
Angle
-90°
-75°
-60°
-45°
-30°
-15°
0°
15°
30°
45°
60°
75°
90°
Value
DMX value
5
24
47
66
85
108
128 or 0
148
169
190
213
234
255
