Showven SPARKULAR WAVERFALL User Manual page 12

CH1 = 128, CH2 = 0, CH3 = 255, CH4 = 0, CH5 = 108, CH6 = 128
DMX control example 2: firing sequence No. 8, firing time 10s
1. Set output nozzle straight up
CH1 = 0, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 0, CH6 = 128
2. Set preset Sequence No. 8
CH1 = 0, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 21, CH6 = 128
3. Firing, default firing duration is 60s
CH1 = 0, CH2 = 0, CH3 = 255, CH4 = 0, CH5 = 21, CH6 = 128
Keep 10s.
4. Firing OFF
CH1 = 0, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 21, CH6 = 128
7. Wireless Control Mode:
When use remote controller, please disconnect DMX cable connection, set machine to Wireless
2.4G to ON status. Match machine with remote controller by Press "A" on remote controller
when machine at Wireless Control interface.
A: OFF / SET, Firing OFF, SET means match machine with remote controller.
B: Firing, vertical up (0°)
C: Firing, according to the sequence setting on machine
D: Clear Material 3s.
Please replace the battery when the indicator light on remote controller is weak.
Battery mode: 9V stacked battery.
Remote controller for SPARKULAR waverFALL is optional accessory.
8. SHOWVEN HOST CONTROLLER ZK6200/6300 control:
When use our host controller control SPARKULAR
the device on HOST CONTROLLER to CIRCLE FLAMER-6CH. Due to host controller with bi-
directional communication with SPARKULAR
allocate a unique DMX address as below:
SPARKULAR No. 1 2
DMX Address 1 7
IMPORTANT NOTICE: Allocate same DMX address to different machine will cause signal
interference and leads to malfunction of machine.
Operation Guide
Δ
1. Install SPARKULAR
a) SPARKULAR waverFALL suggest to be hanged horizontally.
®
b) Make sure the machine is securely installed to avoid falling, make sure to install extra safety
rope for each machine.
c) Check carefully the output nozzle of each machine, make sure the output nozzle is in good
shape and there is no powder aggregate.
®
3 4 5 6 7
13 19 25 31 37 43 49 55 61 67 73 79 85 91 97 103
® waverFALL
waverFALL please press "F3" and switch
®
waverFALL, for each unit of machine please do
8 9 10 11 12 13 14 15 16 17 18
