SSV Works KX-Q3A2 Manual page 5

PANELS AND DASH DISASSEMBLY
A. To begin remove the (2) clips above the center dash compartment by using a clip removal tool. B. Open the dash compartment and remove the (2)
clips.
C. Remove the (2) clips located inside the dash cavity. D. Remove the (2) Phillips screws at the bottom of the center dash piece, located just underneath
the rocker switch panel
A
C
E. Pull out entire center piece of dash, revealing the wiring behind.
E
B
D
5
