SSV Works KX-F65 Quick Start Manual

Kick panel speaker pods for kawasaki teryx krx 1000

Advertisement

Quick Links

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material
or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against
defects in material or workmanship. All SSV Works Speakers are covered by a limited 1 year
warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
PARTS LIST IMAGES
1. KX-F65 Enclosures x2
6. Bracket "D"
A. Attach Bracket "A" to the driver side pod and Bracket "E" to the
passanger side pod as shown using two (2) M6 screws and washers.
- T-30 Torx Driver - 10mm Wrench
2. Bracket "A"
7. Bracket "E"
8. Bracket "F"
3. Bracket "B"
4. Bracket "C"
10. M6 x 16mm Screws
and Washers x14
A
B. Attach Bracket "B" to the driver side pod and Bracket "F" to the
passanger side pod as shown using two (2) M6 screws and washers.
Kawasaki Teryx KRX 1000
Kick Panel Speaker Pods
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
- Drill
- 1/4" Drill Bit
- Punch Tool
5. Threaded Backing Plates x2
11. M6 x 25mm Screw
KX-F65
and Locking Nut x2
B
