SSV Works RG4-Q3A1 Manual page 9

I. Secure the MR1 with the (4) M3.5 screws provided with the MR1.
K. Re-install all factory dash panels.
JVC MR1 WIRING DIAGRAM
A
1
D
I
2
C
3
E
B
J. Secure the backside of the R1 with (2) push pins (circled in blue).
Fasten (2) M6 T30 screws and washers into each front hole
(circled in pink).
K
Once the MR1 is powered on, verify the following presets in the General
Settings: Pre-out = Subwoofer
JVC Harness Adapter, JVC to SSV
1
2
JVC MR1 Radio Harness
3 Amp Power/Ground Harness
4-Pin "Y" Audio Splitter
4
Detail
Connect JVC MR1 radio harness to B-H2367
A
Connect B-H2367 Front Output to B-H2605 Front Input
B
Connect B-H2367 Amp Trigger to B-H2605
C
Connect B-H2367 Rear Output to B-H1403 "Y" Splitter
D
Connect B-H1403 to B-H2605 Rear & Sub Inputs
E
9
Int. Amplifier = On
Description
Description
J
Part #
B-H2367
B-H2605
B-H1403
