SSV Works RG4-Q3A1 Manual page 13

C D
C. Remove factory T25 torx screws located underneath the dash. D. Located on the inside top of the pocket you will have two
holes, route speaker wire though the larger hole. The smaller
hole will be used to mount the pod in Step P.
E E
E. Place the speaker pod in location and resecure the factory screws through the pod brackets on the front and underneath the dash.
F1 F1 F2
P. From the inside-top of the dash, secure the top mounting M6 screw and large washer to the pod through the smaller hole next to the routed speaker
wire (figure F1). Then connect the B-H1149 harness to the speaker cable coming out of the speaker pods (figure P2).
13
