FRONT KICK PODS WIRING DIAGRAM
B
CONNECTING POWER & GROUND CABLE TO BATTERY
Break
off tab
A1. Remove the bottom cover of the fuse holder
by extracting the 2 screws. Break off the right
and left side tabs on the bottom cover.
A
1
Break
off tab
A1
A2. Extract both fuse holder screws and fasten
the fuse.
B
1 Front Speaker Harness (48")
Detail
Connect Front Output from B-H2605 to B-H1909
A
Connect Speaker Pods connectors to B-H2935
B
A2
A3. Attach both the Power Wire and Battery
14
Description
Description
Power
Wire
Terminal Cable to the fuse holder. Reattach
the bottom cover.
Part #
B-H1909
Battery
Terminal
Cable
A3
