SSV Works RG4-Q3A1 Manual page 2

WIRING DIAGRAM OF COMPLETE KIT
2
3
4
Figure 1 is designed to show the installer a reference overview of the complete 3 speaker wiring diagram.
Each installation section will have its own detailed wiring diagram.
1
6
5
7
8
1
Bluetooth Media Receiver w/ 2.7" color display
2
JVC to SSV Harness Adapter, 3 ft.
3
4-Pin "Y" Audio Splitter
4
Amp Wiring Kit Assembly, 10 ft.
5
800.5 Amplifier 32-Pin Universal Harness
6
800 Watt 5 Channel Amplifier
7
Amplifier Rocker Switch for B-A8005
8
Front Kick Pod Enclosure, Left
9
Front Kick Pod Enclosure, Right
Driver/Passenger "Y" Speaker Harness
10
4-Pin Extension Harness, 8 ft.
11
2-Pin Audio, Sub Extension Harness, 8 ft.
12
Loaded Subwoofer Enclosure, 10" 2 ohms
13
11
10
Description
2
9
12
Part #
B-MR1
B-H2367
B-H1403
A-H1Q
B-H2605
B-A8005
B-AMPRS
220-RG4-F65A
220-RG4-F65A
B-H1909
B-H1913
B-H2702
230-RG4-SB10V
13
Figure 1
