Figure 6: Cable routing
Callout Description
1 Cable route for > 24 V cables
2 Cable route for < 24 V cables
Figure 7: Cable ties
Flanges and cable glands
To maintain the UL certification, install the listed flanges and cable glands or blind plugs. See
4. If you are not using cable glands, you must install blind plugs (3). For cable dimensions for the
respective flange and cable gland types, see
14
Table 4.
UniSAB 4 Safety, Installation, and Operating Guide
