Figure 16: Controller port overview
Table 6: Controller port overview
Connector name
X40
X41
X42
X43
X44
X45
X46
X47
UniSAB 4 Safety, Installation, and Operating Guide
Description
Power: 24 VDC
RS485
Status indicator
Display LAN
HDMI
Micro USB
USB-A
SD-card slot
Function
Not used
Not used
Pre-mounted
RJ45 port
Not used
Micro USB
USB-A
Not used
