- Page 1 iSTAR Edge G2 Controller Quick Start Guide March 2021 Document Number:8200-1917-01 Revision: B0 www.swhouse.com...
- Page 2 The trademarks, logos, and service marks displayed on this document are registered in the United States [or other countries]. Any misuse of the trademarks is strictly prohibited. All trademarks not owned by Johnson Controls are the property of their respective owners, and are used with permission or allowed under applicable laws.
-
Page 3: Compatible Readers
Overview The iSTAR Edge G2 Controller is supported on C•CURE 9000 version 2.80 and later with firmware version 6.8.x. UL Listed Models Table 1: iSTAR and Components Wiring Specifications Part Number Description GSTAR004 iSTAR Edge G2, 4 readers, in metal enclosure GSTAR004-MB iSTAR Edge G2, 4 readers, board only GSTAR004-MBP... -
Page 4: Specifications And Requirements
Specifications and Requirements Specifications Table 2: Environmental and Electrical Specifications iSTAR Edge G2 Specifications Environmental Operational Temperature 32° F (0° C) to 120° F (49° C) Electrical Power 12 VDC, 5 A max 24 VDC, 5 A max PoE, PoE+ (PoE/PoE+ module must be set to 24 V) Auxiliary Power 12 VDC, 350mA Wiegand Ports... -
Page 5: Grounding Requirements
Phihong injectors , or power-limited, PoE injectors, which are UL 294 listed. NOTE Ensure PoE/PoE+ modules are set to 24 V. IEEE 802.3 (AT or AF) compliance was not verified to UL294. PoE installations are UL listed for Mode B only. Grounding Requirements ■... - Page 6 Ethernet Connection ■ x2 Ethernet port onboard - supports 10/100/1000 Base-T Ethernet connections. Communications ■ Full 256-bit encryption. All cabling must be shielded. NOTE...
-
Page 7: Installation
Installation Mounting the Enclosure The iSTAR Edge G2 module must be installed in a GSTAR-CAN to maintain UL listing. The system must be installed indoors within a protected premises in accordance with the National Electrical Code (NFPA70), and NOTE relevant local authority regulations. 1. - Page 8 Figure 1: iSTAR Edge G2 Enclosure The WIFI/BLE MODULE *PHASE 2* shown in Figure 1 is a future option which may not be included on your current iSTAR Edge G2 NOTE board.
- Page 9 Wiring Wiring Specifications and Components Table 4: iSTAR and Components Wiring Specifications Signal From Shield Max Length RS-485 Comm, iSTAR Edge RM and I/O 4000 ft (1212m) Modules two wire Power iSTAR Edge RM and I/O 22/18 Range of 600 ft to Modules 1500 ft, depending on AWG used.
- Page 10 NO/NC Double Resistor 1K This is the standard Software House method of supervision. 1K Ω is considered Secure and 500 Ω or 2K Ω are considered Alert. The wiring for NO and NC is different, as shown in Figure Figure 2: NO / NC Double Resistor 1K The NO/NC Double Resistor method will report: ■...
- Page 11 Dry Relay Wiring Figure 3: Dry Relay Wiring Figure 3 shows a dry relay wiring setup. ■ Max current is 3A at 30 VAC/VDC. ■ Use NO or NC as appropriate. ■ The jumper is in the Dry position. Wet Relay Wiring Figure 4: Wet Relay Wiring Figure 4 shows a wet relay wiring setup for a normal, NO latch.
- Page 12 Wet Wiring for a MagLock Figure 5: Wet Relay Wiring for MagLock Figure 5 shows wet wiring for a magnetic lock. ■ GND and NC pins are used for energized magnetic locks. ■ The jumper is in the Wet position. Wiring for AC Fail / Low Batteries Figure 6: AC Fail / Low Battery wiring Figure 6 shows wiring for AC fail / low battery condition.
-
Page 13: Wiegand Readers
Readers Wiegand Readers Figure 7: Wiegand Readers Figure 7 shows direct Wiegand signaling read head connections. RS485 Readers Figure 8: RS485 Readers Figure 8 shows RS485 full duplex and half duplex reader connections.
