2.6
Power Modules
2.6.1
Front View
For
UPS, there are five power modules, three of which must be installed
1250/ 1263kVA
at the right-hand side of the UPS system cabinet and the remaining two at the left-
hand side of the UPS system cabinet.
Each power module's capacity is up to 252.6kVA/ 250kW.
(Figure 2-6: 1250/ 1263kVA UPS_ Front View of the Power Modules)
Ultron DPM Gen2 Series
20
