Document History Page
Document Title: CY8C20x36/46/66, CY8C20396 CapSense
Document Number: 001-12696
Revision ECN Origin of Change
** 766857 HMT
*A 1242866 HMT
*B 2174006 AESA
*C 2587518 TOF/JASM/MNU/
HMT
*D 2649637 SNV/AESA
Document Number: 001-12696 Rev. *D
TM
Applications
Submission Date
See ECN New silicon and document (Revision **).
See ECN Add features. Update all applicable sections. Update specs.
Fix 24-pin QFN pinout moving pins inside. Update package
revisions. Update and add to Emulation and Programming
Accessories table.
See ECN Added 48-Pin SSOP Part Pinout
Modified symbol R
Specification
Added footnote in Table DC Analog Mux Bus Specification
Added 16K FLASH Parts. Updated Notes, Package Diagrams
and Ordering Information table. Updated Thermal Impedance
and Solder Reflow tables
10/13/08 Converted from Preliminary to Final
Fixed broken links. Updated data sheet template.
Added operating voltage ranges with USB
ADC resolution changed from 10-bit to 8-bit
Included ADC specifications table
Included Comparator specification table
Included Voh7, Voh8, Voh9, Voh10 specs
Flash data retention – condition added to Note
Input leakage spec changed to 1 μA max
GPIO rise time for ports 0,1 and ports 2,3 made common
AC Programming specifications updated
Included AC Programming cycle timing diagram
AC SPI specification updated
The VIH for 3.0<Vdd<2.4 changed to 1.6 from 2.0
Added USB specification
Added SPI CLK to P1[0]
Updated package diagrams
Updated thermal impedances for QFN packages
Updated F
Updated voltage ranges for F
Update Development Tools, add Designing with PSoC
Designer. Edit, fix links, notes and table format. Update R
formula, fix TRise parameter names in GPIO figure, fix Switch
Rate note. Update maximum data in Table 20. DC POR and
LVD Specifications.
03/17/2009 Changed title to "CY8C20x36/46/66, CY8C20396
CapSense™ Applications". Updated data sheet Features, pin
information, and ordering information sections. Updated
package diagram 001-42168 to *C.
CY8C20x36/46/66, CY8C20396
Description of Change
to R in Table DC Analog Mux Bus
VDD GND
parameter in Table 23
GPIO
and F
SPIM
in Table 30
SPIS
IN
Page 33 of 34
