Electrical Specifications

This section presents the DC and AC electrical specifications of the CY8C20x36/46/66, CY8C20396 PSoC devices. For the latest
electrical specifications, confirm that you have the most recent data sheet by visiting the web at
Figure 9. Voltage versus CPU Frequency
5.5V
1.71V
750 kHz
The following table lists the units of measure that are used in this section.
Table 9. Units of Measure
Symbol
°C degree Celsius
dB decibels
fF femto farad
Hz hertz
KB 1024 bytes
Kbit 1024 bits
kHz kilohertz
ksps kilo samples per second
kΩ kilohm
MHz megahertz
MΩ megaohm
μA
microampere
μF
microfarad
μH
microhenry
μs
microsecond
μW
microwatts
Document Number: 001-12696 Rev. *D
3 MHz
24 MHz
CPU Frequency
Unit of Measure
CY8C20x36/46/66, CY8C20396
Figure 10. IMO Frequency Trim Options
5.5V
1.71V
750 kHz 3 MHz
Symbol
mA milli-ampere
ms milli-second
mV milli-volts
nA nanoampere
ns nanosecond
nV nanovolts
Ω
ohm
pA picoampere
pF picofarad
pp peak-to-peak
ppm parts per million
ps picosecond
sps samples per second
s sigma: one standard deviation
V volts
http://www.cypress.com/psoc.
SLIMO SLIMO SLIMO
Mode Mode Mode
= 01 = 00 = 10
6 MHz 12 MHz 24 MHz
IMO Frequency
Unit of Measure
