Cypress CapSense CY8C20396 Specification Sheet

Cypress evaluation pod specification sheet

Advertisement

Quick Links

Features
1.71V to 5.5V Operating Range
Low Power CapSense™ Block
Configurable Capacitive Sensing Elements
Supports Combination of CapSense Buttons, Sliders,
Touchpads, Touch Screens, and Proximity Sensor
Powerful Harvard Architecture Processor
M8C Processor Speeds Running to 24 MHz
Low Power at High Speed
Interrupt Controller
Temperature Range: -40°C to +85°C
Flexible On-Chip Memory
Three Program/Data Storage Size Options:
• CY8C20x36: 8K Flash / 1K SRAM
• CY8C20x46: 16K Flash / 2K SRAM
• CY8C20x66: 32K Flash / 2K SRAM
50,000 Flash Erase/Write Cycles
Partial Flash Updates
Flexible Protection Modes
In-System Serial Programming (ISSP)
Full-Speed USB
Available on CY8C20396 and CY8C20666 Only
12 Mbps USB 2.0 Compliant
Eight Unidirectional Endpoints
One Bidirectional Control Endpoint
Dedicated 512 Byte Buffer
Internally Regulated at 3.3V
Precision, Programmable Clocking
Internal Main Oscillator: 6/12/24 MHz ± 5%
Internal Low Speed Oscillator at 32 kHz for Watchdog and
Sleep Timers
Precision 32 kHz Oscillator for Optional External Crystal
(CY8C20x46/66 only)
0.25% Accuracy for USB with No External Components
(CY8C20396 and CY8C20666 only)
Programmable Pin Configurations
Up to 36 GPIO (Depending on Package)
Dual Mode GPIO: All GPIO Support Digital IO and Analog
Input
25 mA Sink Current on All GPIO
Pull up, High Z, Open Drain Modes on All GPIO
CMOS Drive Mode(5 mA Source Current) on Ports 0 and 1:
• 20 mA (at 3.0V) Total Source Current on Port 0
• 20 mA (at 3.0V) Total Source Current on Port 1
Selectable, Regulated Digital IO on Port 1
Configurable Input Threshold on Port 1
Hot Swap Capability on all Port 1 GPIO
Cypress Semiconductor Corporation
Document Number: 001-12696 Rev. *D
Versatile Analog Mux
Common Internal Analog Bus
Simultaneous Connection of IO
High PSRR Comparator
Low Dropout Voltage Regulator for All Analog Resources
Additional System Resources
I
• Selectable to 50 kHz, 100 kHz, or 400 kHz
• No Clock Stretching Required (under most conditions)
• Implementation During Sleep Modes with Less Than
• Hardware Address Validation
SPI™ Master and Slave: Configurable 46.9 kHz - 12 MHz
Three 16-Bit Timers
Watchdog and Sleep Timers
Internal Voltage Reference
Integrated Supervisory Circuit
Complete Development Tools
Free Development Tool (PSoC Designer™)
Full Featured, In-Circuit Emulator and Programmer
Full Speed Emulation
Complex Breakpoint Structure
128K Trace Memory
Package Options
CY8C20x36:
• 16-Pin 3 x 3 x 0.6 mm QFN
• 24-Pin 4 x 4 x 0.6 mm QFN
• 32-Pin 5 x 5 x 0.6 mm QFN
CY8C20x46:
• 16-Pin 3 x 3 x 0.6 mm QFN
• 24-Pin 4 x 4 x 0.6 mm QFN
• 32-Pin 5 x 5 x 0.6 mm QFN
CY8C20396: 24-Pin 4 x 4 x 0.6 mm QFN
CY8C20x66:
• 32-Pin 5 x 5 x 0.6 mm QFN
• 48-Pin 7 x 7 x 1.0 mm QFN (with USB)
• 48-Pin SSOP
198 Champion Court
CY8C20x36/46/66, CY8C20396
CapSense™ Applications
2
C™ Slave:
100 µA
,
San Jose
CA 95134-1709
408-943-2600
Revised March 17, 2009
[+] Feedback
