D4 Valve: Dimensions in mm
DN A B
40 6 7
50 13 12
65 21 20
80 30 25
100 49 25
125 58 35
150 78 40
Inch
1,5" 6 7
2" 13 12
2,5" 15,3 20
3" 27,9 20
4" 49 25
6" 78 40
18
9. Technical Data
9.5.

Valve stroke / Opening cross section

valve
stroke H1 stroke H2
C
upper shaft lower shaft
22 32 29
22 37 34
22 45 42
36 50 47
36 50 47
43 60 57
53 65 62
22 32 29
22 37 34
22 45 42
22 45 42
36 50 47
53 65 62
valve
open closed
D4 SL Valve: Dimensions in mm
DN A
40 4
50 9
65 13
80 24
100 43
125 58
150 78
Inch
1,5" 4
2" 9
2,5" 14,3
3" 20,9
4" 43
6" 78
stroke H1
B C
upper shaft
4 22 29
9 22 34
12 22 45
25 36 50
25 36 50
35 43 60
40 53 65
4 22 29
9 22 34
14 22 39
20 22 45
25 36 50
40 53 65
Double Seat Mix Proof Valve
APV DELTA D4 / D4 SL
Instruction Manual: GB - rev. 3
GB
stroke H2
lower shaft
26
31
42
47
47
57
62
26
31
36
42
47
62
