9. Technical Data
9.5. Pneumatic air consumption at 6 bar control pressure
Actuator
Ø 110 mm
Ø 165 mm
9.6. Valve stroke / Opening cross section (X)
DN, Inch
25, 1"
40, 1,5"
50, 2"
65, 2,5"
3"
80
100, 4"
per stroke
Stroke
13
13
16
23
23
28
28
UK
NL
2.1
4.5
X
10
10
13
20
20
25
25
12
