Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
Pit Stop/idle mode: This feature is not available in this firmware.
Š
The following remote start features can be configured via the information display:
Š
Š Climate control
Š Heated seats/steering wheel
Š Runtime (For best results, program the runtime to match the OEM setting.)
Š Remote start enable/disable
The optional Plug & Play THFOD2 T-Harness is sold separately
Š
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
All T-Harness wires not listed in the diagram are not required for the installation.
Š
All connectors are displayed from the wire side (unless specified otherwise).
Š
Refer to the "Vehicle connections" following the installation diagram.
Š
Conditions and Limitations
This installation enables the OEM remote starter and the remote start system will not work in the following conditions:
Š The ignition is on.
Š The alarm system is triggered.
Š The hood is open.
Š The transmission is not in Park (P).
Š The vehicle battery voltage is too low.
Š The service engine light is on.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Tach: An optional connection required on some remote starters, which do not support a tach signal in D2D.
5
403.FORD11 2.07 2013 Ford Fusion
©2022 VOXX•DEI LLC. All rights reserved.
THFOD2
Refer to the Quick Reference Guide section for more details.
Keys required for
or
programming
1 Keys required 0
for operation
