Functions compatible with the 2014 Mazda 3 (Smart Key)
3x LOCK START (Start control using OEM
Remote)
3x LOCK STOP (Stop control using OEM
Remote)
Brake Status (foot brake)
Control of aftermarket alarm with OEM
remote
Door Lock Control
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Remote Start Ready
Remote Start Takeover
Tach / RPM Output
Trunk / Hatch Release
403.MA3
v2.42.104
2014 Mazda 3 (Smart Key)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIRECTWIRE VOXX-DEI DB3 and is the answer not in the manual?

Questions and answers

Related Manuals for Directechs DIRECTWIRE VOXX-DEI DB3

Summary of Contents for Directechs DIRECTWIRE VOXX-DEI DB3

  • Page 1 403.MA3 v2.42.104 2014 Mazda 3 (Smart Key) Functions compatible with the 2014 Mazda 3 (Smart Key) 3x LOCK START (Start control using OEM Entry Monitoring Hood Pin Remote) Entry Monitoring Trunk/Hatch Pin 3x LOCK STOP (Stop control using OEM Ignition Status Remote) Immobilizer Bypass-Data No Key Req'd Brake Status (foot brake)

  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings Wiring diagram Locating components in the vehicle Vehicle connections Module programming For Convenience-Only programming, see next section. Module programming for convenience only (skip transponder) SmartStart Pro/Digital RF Kit/XL202 installation notes LED diagnostics and troubleshooting Parking light error codes Soft reset Hard reset...

  • Page 3: Introduction

    • XL202 & Analog RF Kit Notes • This module can only be flashed and configured using DirectLink at www.directechs.com. • RSR mode is not compatible with vehicles equipped with a manual transmission. 403.MA3 2.42.104 2014 Mazda 3 (Smart Key)

  • Page 4: Pre-Installation And Application Warnings

    Pre-installation and application warnings This section highlights important information for this specific firmware and will assist in pricing accordingly, as START HERE well as bringing awareness to any operational or vehicle limitations. Compatibilities and Requirements T-Harness Keys required for Keys required T-Harness is not compatible.

  • Page 5: Wiring Diagram

    Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( HS CAN Low: Red, pin 8 HS CAN High: White, pin 7 Start/Stop Unit (-) Parking Lights: (white conn.

  • Page 6: Locating Components In The Vehicle

    Locating components in the vehicle Accessing the parking light circuit 1. Grab parking light handle and pull in the direction of the arrow. 2. Push the clip to remove the parking light switch. 3. Remove the white cover to expose the connector. 4.Access the parking light connector and wire.

  • Page 7: Vehicle Connections

    Vehicle connections The connection information listed below is specific to the 2014 Mazda 3 (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes. Data 14-pin blue connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color H1/1...
  • Page 8 Input 10-pin black connector (H3) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color H3/1 Green No Connection No Connection H3/2 Blue No Connection No Connection H3/3 Red/White No Connection No Connection H3/4 White/Violet No Connection No Connection H3/5 Violet/Black No Connection...

  • Page 9: Module Programming

    Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. Convenience-Only programming, see next section. Ensure vehicle is in a safe location and cannot move forward during programming. The harnesses must be connected in this exact order: Connect the 14-pin.

  • Page 10: Module Programming For Convenience Only (Skip Transponder)

    Module programming for convenience features only (skip transponder) Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. The harnesses must be connected in this exact order: 1.

  • Page 11: Smartstart Pro/Digital Rf Kit/Xl202 Installation Notes

    SmartStart Pro/Digital RF Kit/XL202 installation notes The DB3 Remote Start Ready (RSR) solution offers four (4) configuration options to control your system: 3x OEM Lock Remote Start Activation (if applicable, refer to the "vehicle function compatibilities" section), SmartStart Pro, Digital RF Kit, XL202 & Analog RF Kit (all sold separatly).

  • Page 12: Led Diagnostics And Troubleshooting

    LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power.
  • Page 13   Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence. received. Flashes green Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence. Flashes red &...

  • Page 14: Parking Light Error Codes

    Parking light error codes The parking lights on your vehicle will flash a specific number of times 3 seconds following an unscheduled shutdown. Each flashing pattern is described below. Flashes Diagnostic Runtime expired. Over-rev shutdown. Low or no RPM. Shutdown without remote. Brake shutdown.

  • Page 15: Limited One Year Consumer Warranty

    Limited 12 Months Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor.

  • Page 16: Qrg (Customer Copy)

    Quick Reference Guide (customer copy) Sending commands to your vehicle Pit stop/idle mode Whether you want to remote start the engine, lock/unlock the doors or pop the trunk, there Stop the vehicle in a safe parking spot and put the gear gear in Park are 3 possible ways you can send commands to your vehicle, using the: in Park (P).
  • Page 17 List of available commands Notes Note that the information below is for many Viper, Clifford, Python, Avital, Automate, Autostart and AstroStart models. Icons and commands may differ depending on the model and options purchased. Refer to your authorized installation center for more specific information.
