Wiring diagram without OEM Remote Start and
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Headlight Switch
(-) Parking Lights:
Parking Light
Gray or Yellow,
Interrupt: Pin 4
pin 11
Cut
(-) Hood Input
(AC) Tach Input
(+) Ignition Input
(+) 12V
(-) Ground
7 403.FORD11 2.07 2013 Ford Fusion
©2022 VOXX•DEI LLC. All rights reserved.
with T-Harness (THFOD2)
Gateway Module
(black conn. on OBDII connector)
Parking Lights Interrupt (vehicle side): Yellow/Red
Parking Lights Interrupt (conn. side): Orange/Red
Trunk Release
(black or brown conn. at trunk release switch)
1 2 3
4 5 6
Hood Pin
(+) 12V
(-) Parking Lights Output: Brown/Red
(-) Trunk Release Ouptut: Black/White: 1
(-) Trunk Release:
Gray/Yellow, pin 6
(AC) Tach Ouptut: Violet/White: 5
(+) Ignition Status Output: Gray/Black: 7
).
4-pin Connectors
Type 1
Type 2
NOT USED
Remote Start Safety
Override Switch
THFOD2 (optional T-Harness)
XKD2D65
D2D
only
White/Black N.C.
