UM0178
Table 10.
Column Row
B 25
B 26
B 27
C 19
C 26
C 27
C 29
C 30
D 17
D 18
D 19
D 25
D 26
D 27
D 29
D 30
4.11

Prototyping area

A standard 100mils prototyping area is available for user's application.
4.12

Jumpers summary

Table 11. summarizes jumpers available on the MB467 Airbag Eva Board.
Table 11.
Jumper
J1
J2
J3
J4
J5
CPU Board connector pinout
Name
CS_D1 Chip select for Deployment Driver of L9658
IF4 Current Feedback for channel 4 Raw or Data output for channel 4 of the
L9658
AOUT2 Analog output for loop diagnostic for L9654
DICH1 Channel 1 Satellite input simulation for L9658
MOSI_A Arming SPI: Data In
CS_A2 Chip select for Arming Interface of L9654
CS_D2 Chip select for Deployment Driver of L9654
DEPEN1 Deployment enable input for L9658
MSG2 Message waiting for L9654
BCKFLT Buck fault output
DICH2 Channel 2 Satellite input simulation for L9658
SCLK_A Arming SPI: Clock
MISO_A Arming SPI: Data Out
CS_S2 Chip select for Satellite Interface of L9654
MSG Message waiting for L9658
CS_A1 Chip select for Arming Interface of L9658
Jumpers summary
Name Figure
SQUIB Figure 8
SQUIB Figure 8
SQUIB Figure 8
SQUIB Figure 8
SATELLITE Figure 4
Description
Driver Output for Channel 0 for L9658
Driver Output for Channel 1 for L9658
Driver Output for Channel 2 for L9658
Driver Output for Channel 3 for L9658
L9658 satellite channel 1:
Open: real satellite (ICH1 on J5 pin 1)
Closed: simulated satellite (load driven by DICH1)
Description
4 Hardware
25/37
