4 Hardware
Name
SQL7
SQL9
SQL10
SQL11
SQL12
GND0
GND1
GND2
GND3
GND4
GND5
GND6
GND7
GND9
GND10
GND11
GND12
If no squibs are connected to the board, it is possible to simulate squib loads by closing the
jumpers J1-J4, J9-J12 and J52-J53 and J56-J57.
Table 6.
Name
J1
J2
J3
J4
J9
J10
J11
J12
J52
J53
J56
J57
J13
20/37
Figure
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Squib dummy loads
Figure
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Figure 8
Description
Low Side Driver Output for Channel 7 for L9658
Low Side Driver Output for Channel 0 for L9654
Low Side Driver Output for Channel 1 for L9654
Low Side Driver Output for Channel 2 for L9654
Low Side Driver Output for Channel 3 for L9654
Power Ground for Loop Channel 0 for L9658
Power Ground for Loop Channel 1 for L9658
Power Ground for Loop Channel 2 for L9658
Power Ground for Loop Channel 3 for L9658
Power Ground for Loop Channel 4 for L9658
Power Ground for Loop Channel 5 for L9658
Power Ground for Loop Channel 6 for L9658
Power Ground for Loop Channel 7 for L9658
Power Ground for Loop Channel 0 for L9654
Power Ground for Loop Channel 1 for L9654
Power Ground for Loop Channel 2 for L9654
Power Ground for Loop Channel 3 for L9654
Description
Driver Output for Channel 0 for L9658
Driver Output for Channel 1 for L9658
Driver Output for Channel 2 for L9658
Driver Output for Channel 3 for L9658
Driver Output for Channel 4 for L9658
Driver Output for Channel 5 for L9658
Driver Output for Channel 6 for L9658
Driver Output for Channel 7 for L9658
Driver Output for Channel 0 for L9654
Driver Output for Channel 1 for L9654
Driver Output for Channel 2 for L9654
Driver Output for Channel 3 for L9654
Power Ground for Loop Channel 0 - Channel 7 for
L9658
UM0178
