Schritte zur Inbetriebnahme

Select
Language Date and time

Deutsch
17.02.2020
English
Francais
...
Automatischer oder manueller Test

Set Select
System type
 
TEST
√ Measurement
√ Coupling
√ Earth connection
√ Outputs
100%
Steps for Commision

Select
profile

Power circuit
DC
Control circuit
AC
Generator
3AC
High capacitance
Inverter >10Hz
Inverter <10Hz
Customized
Automatic or manual test
Insulation fault
0
+
R(an) 40 k / 10 k
isoHR685W-x-I-B_D00261_06_Q_DEEN/03.2024
ISOMETER® isoHR685W-x-I-B
 
Set
Response value
for Alarm 1

40 kΩ
IT-System
OK
2 GΩ
120 k
R(an) 40 k / 10 k
Set
Response value
for Alarm 2

10 kΩ
