workmanlike manner;
the appliance can be used by children aged no less than
8 years and by people with reduced physical, sensory or
mental capabilities, or without experience or the neces-
sary awareness, provided they are supervised or after
they have received instructions relating to the safe use
of the appliance and understanding the dangers inherent
to it;
before starting the automation make sure that people are
not in the immediate vicinity;
before proceeding with any cleaning and maintenance
operations on the automation, disconnect it from the
electricity mains;
children must be supervised to ensure that they do not
play with the appliance;
Periodically examine the system to check for the
presence of imbalances and signs of mechanical
wear, damage to cables, springs and support parts.
Do not use if repair or adjustment is necessary.

2 - INTRODUCING THE PRODUCT

2.1 - Description of the product and intended use

KUBEU is a compact Bluetooth control module for automations,
which allows you to activate two configurable relay contacts, using
a smartphone and a dedicated application. It can be installed on
the wall/panel using the (removable) fixing tabs, or recessed (e.g.
in junction boxes). It can be powered by connecting directly to the
Key Automation control units, or through a dedicated AC/DC power

2.2 - Technical data

MODEL
Power Supply
Maximum power
Working cycle
Maximum current for each output
Maximum voltage for each output
Output settings
Bluetooth frequency
Antenna
Typical operating distance *
Degree of protection
Operating temperature
Electrical insulation class
Dimensions with fixing tabs
Dimensions without fixing tabs
Weight
Minimum requirements for smartphone apps
* The presence of metal, wire mesh or concrete structures, or being inside a vehicle, can significantly influence the performance.
WARNING !
Packaging components (cardboard, plastic,
etc.), duly separated, must be placed in the
appropriate bins. Device components such as
electronic boards, metal parts, batteries, etc.
must be separated and differentiated. For the
methods of disposal, the rules in force in the
place of installation must be applied. DO NOT
DISPOSE IN THE ENVIRONMENT!
Key Automation S.r.l reserves the right to amend the-
se instructions if necessary; they and/or any more
recent versions are available at www.keyautomation.
com
supply.
Examples of devices that can be connected to the KUBEU outputs
are lighting devices, electric locks, irrigation systems, tubular motors
for roller shutters, home automation interfaces, provided they are
within the limits of use indicated in paragraph 2.2.
KUBEU
12-24 VAC 50/60 Hz / 12-35 VDC
0,6 W
continuo
5 A @ 30 V (resistive load)
35 VAC / 50 VDC
Bistable or timed
2,4 GHz
integrated
< 30 m
IP 4X
-20 +55 °C
III
70x60x31 mm
50x50x31 mm
0,045 kg
iOS 12, Android 9
