A-3
Online Editing
Programs can be corrected while the PLC is running.
Online editing cannot be performed when using the simulator.
A-3-1 Transferring Programs to PLC
In preparation for online editing, connect the computer and the PLC, and transfer the program from
the computer to the PLC.
Normally, online editing is performed on a program uploaded from a running PLC.
1 Establish an online connection.
Physically connect the computer to the PLC in
advance.
For details on establishing an online connection
with the PLC, refer to CX-Programmer
Operation Manual.
Select PLC - Work Online.
A confirmation dialog box will be displayed.
Click Yes.
An online connection will be established
between the computer and PLC.
A-3 Online Editing
A
A-9
