2-7
Simulated Transition Test
Before creating the actions, check how the program operates when the transition conditions are
satisfied. The simulator will allow you to test programs using only the computer.
2-7-1 Online Connection to Simulator
Transfer the program to the simulator.
1 Establish an online connection.
Select Simulation - Work Online Simulator.
An online connection will be established
between the computer and the simulator. The
Download Options dialog box will be
displayed.
Click OK.
The Download dialog box will be displayed.
When the data transfer is completed, the
Download successful message will be
displayed.
2-7 Simulated Transition Test
2-25
