Creating Projects

Start CX-Programmer, and select the device type.
1 Start CX-Programmer.
On the desktop, select Start - All Programs -
OMRON - CX-One - CX-Programmer - CX-
Programmer.
CX-Programmer will start, and the main
window will be displayed.
For details of the main window, refer to A-1-1
Main Window.
2 Create a new project.
Click New.
The Change PLC dialog box will be
displayed.
3 Select the device type and the
network type.
Select the device type from the Device Type
drop-down list.
Click Settings.
The Device Type Settings dialog box will be
displayed.
Settings for CJ1G-CPU42-H will be used here
as an example.
