2-8 Creating Action Blocks
Select D from the drop-down list.
D 1s will be displayed as the AQ. This means
that the action will be executed 1 second after
the step becomes active.
2
Double-click 1s.
Type "3", and press the Enter key.
D 3s will be displayed as the AQ.
The SFC chart is now fully completed.
Save the project.
