Wallbox eVolve Series - Installation Manual
2
I M P O R TA N T S A F E T Y I N S T R U C T I O N S
The Charge Point is designed to be installed both in indoor and outdoor areas. For each of
the different conditions of installation, the unit must be installed safely and ensure adequate
protection.
• Charge Point must not be installed in
areas where potential risk of explosions
are.
• Do not install the Charge Point where
falling objects
equipment.
• The Charge Point can be installed in
locations with non-restricted access.
• The surface where the Charge Point is
placed must withstand the mechanical
forces.
• This unit shall not be used for any other
purpose than electric vehicle charging
modes as specified in IEC 61851-1:2017.
• Do not modify this unit. If modified,
CIRCONTROL will reject all responsibility
and the warranty will be void.
• Comply strictly with electrical safety
regulations according to your country
Refer to TECHNICAL DATA section for more information about environmental installation conditions.
04
Read carefully all the instructions before starting in order
to ensure properly installation of the Charge Point.
may damage the
• Do not use any adapter, except those
approved by the EV manufacturer.
Adapter only allowed to eVolve models
with socket-outlet.
• Do not make repairs or manipulations
with the unit energized.
• Only trained and qualified personnel
should have access to low-voltage
electrical parts inside the unit.
• Check the installation annually by
qualified technician.
• Remove from service any item that has a
fault that could be dangerous for users
(broken plugs, caps that don't close...).
• Use only Circontrol supplied spare
parts.
• Do not use this product if the enclosure
or the EV connector is broken, cracked,
open, or shows any other indication of
damage.
