- Page 1 Single-phase supply connection for eVolve T...
- Page 2 Single-phase supply connection for eVolve T Name: Number: Version: Category: Hardware Issued: November 2021 CONTENT 1. Subject ......................... 3 2. Models Affected ....................3 3. Safety & Security information ................3 4. Hardware required ....................4 5. Procedure ......................4...
- Page 3 Models Affected Any eVolve T with an RCD in which the test button is linked to the third terminals. Safety & Security information Read all the instructions before using and install this product.
- Page 4 Hardware required REF. QTY. PICK. DESC. Screwdriver Procedure STEP ACTION Check the connection diagram of the RCD. If the test button is connected to the third terminals of the RCD, as shown in the following example, proceed with this manual. If the test button is connected to the first terminals of the RCD, there’s no need to apply any modification.
- Page 5 Untighten the cables connected to the first terminals, from the upper and lower side of the RCD, and reconnect them on the third terminals of the RCD. In case of having problems with the length of any of the cables, replace it by a larger one with the same characteristics as the original;...
