Summary of Contents for Circontrol eVolve Series

Page 1 Installation Manual eVolve Series...
Page 2 Revision log Date Version Description 02/2025 M429B10-03-25A C63 One model addition Format change. Changes in the following sections: 04/2024 M429B10-03-24A 3, 5, 6 11/2023 v4.2 Changes in the following sections: 3, 4, 5 ,6 — — Previous versions...
Page 3 C O P Y R I G H T I N F O R M A T I O N This document is copyrighted, 2025 by Circontrol, S.A. All rights are reserved. Circontrol, S.A. reserves the right to make improvements to the products described in this manual at any time without notice.
Page 4 Here’s the guide to install your eVolve...
Page 5 1 — So, hello! 2 — Before installation A - Important safety instructions B - Electrical wiring considerations 3 — Overview 4 — Dimensions 5 — Installation A - Minimum distances B - Plate fixation C - Positioning D - Opening E - Unit fixation F - Connections G - Wiring...
Page 6 It is mandatory to follow the basic security information supplied in this manual to ensure safe and proper installation. Failure to follow safety instructions may involve personal injury, equipment damage and danger of death. CIRCONTROL is not responsible for events arising from such breach. THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT...
Page 7 • Complies with IEC 61851, Electric vehicle conductive charging system (IEC 61851-1 and IEC 61851-21-2). • Complies with IEC 62196, Plugs, socket-outlets, vehicle couplers and vehicle inlets (IEC 62196-1 and IEC 62196-2). • Complies with Directives: 2014/35/EU, LVD;2014/30/EU, EMC. Complies with The Electrical equipment (safety) regulations 2016 •...
Page 8 • Do not use this unit if the enclosure the warranty will be void. or the EV connector is broken, cracked, open, or shows any other indication of damage. CIRCONTROL — eVolve Series — Installation Manual...
Page 9 Electrical wiring considerations Take into consideration this section before start wiring connections of the Charge Point. 1 - E L E C T R I C A L P R O T E C T I O N S Charge Point may not include elements of electrical protection. If this equipment has internal electrical protections, they are installed for each socket-outlet for the protection of the user against an electrical failure, according to the international standard IEC 61851-1:2017.
Page 10 Overview What’s included: Installation CirCarLife Charge Point Installation CirCarLife Manual RFID Card Manual RFID Card Cable Glands eVolve Keys Installation Kit CIRCONTROL — eVolve Series — Installation Manual...
Page 11 Master Smart Satellite 1 — Hat 4 — Touch screen 8” 7 — Wall support 2 — Key lock access 5 — RFID Reader 8 — Base 3 — Display LCD 6 — Plugs Plugs may vary depending on the model.
Page 12 Dimensions CIRCONTROL — eVolve Series — Installation Manual...
Page 13 Measures in mm...
Page 14 The installation kit has been tested on a concrete wall. Before the installation, a qualified installer must check that the wall is in a perfect condition, and which screws and anchors are suitable for that conditions. CIRCONTROL — eVolve Series — Installation Manual...
Page 15 Minimum distances When installing the unit, some space shall be reserved for usability, maintenance and safety reasons. Please comply accordingly to your country specifications. The next picture shows the minimum distances: ≥ 1000 Measures in mm Front view...
Page 16 Wall plates: 16.3 58.9 Measures in mm CIRCONTROL — eVolve Series — Installation Manual...
Page 17 Plate fixation 1. Use the supplied template to mark and drill the fixing points, and install the plate correctly on the wall. 2. Mark and drill the bottom hole for later fixation of the unit. ≥ 1000 Measures in mm Front view...
Page 18 Positioning Place the unit on the previously installed wall plate, matching the protruding parts with the holes in the unit plate. CIRCONTROL — eVolve Series — Installation Manual...
Page 19 Opening 1. Use the provided keys in order to open the unit. 2. Pull outward the Tamper switch to operate the Charge Point. The Smart model has reversed locks compared to those shown in the picture. Tamper Switch: The Charge Point has a security switch (anti-tamper protection) installed that will avoid any charging session if the doors are opened.
Page 20 Unit fixation Tighten the 60 mm long screw together with the sealing washer in order to secure the unit to the wall and make sure all components remain as by default before proceeding. CIRCONTROL — eVolve Series — Installation Manual...
Page 21 Connections Introduce connections into the Charge Point: Remove one or two of the upper or lower plugs that fit your electrical connection (A or B) Put your electrical connections inside the Charge Point. Put the cable gland according to the chosen plug. Put your communications connection inside the Charge Point.
Page 22 Type of cable allowed by the terminal block: Aluminium Al/Cu & copper Do not forget to connect the ground cable to the ground terminal Make sure all screws are securely tightened at 4.5 Nm CIRCONTROL — eVolve Series — Installation Manual...
Page 23 WIRING DIAGRAM eVOLVE SMART THREE-PHASE Charge Point Connect to the 400VAC. • • If the Power Supply is Single-Phase, connect L1 and N. • Use provided cable glands in order to maintain the IP protection Disconnector maximum cross-section: 35 mm Type of cable allowed by the terminal block: Aluminium Al/Cu &...
Page 24 Depending on the position given to the Dip-Switch, the equipment will limit the current to the defined maximum amperage value. To limit the current of the eVolve, the table in the next page must be followed: CIRCONTROL — eVolve Series — Installation Manual...
Page 25 Whenever the position of the DIP Switch is changed, to apply the changes, the equipment must be restarted by disconnecting the power supply. DIP-SWITCH eVolve Limit Current (A) Position 10 A 16 A 20 A 25 A 32 A 32 A 32 A 32 A 32 A...
Page 26 B l u e ( B l i n k i n g ) ( 1 ) C h a r g i n g B l u e F a u l t / D i s a b l e R e d CIRCONTROL — eVolve Series — Installation Manual...
Page 27 7 — O P E R A T I O N Check no abnormal noise appears while the unit is charging. 8 — P R E V E N T I V E M A I N T E N A N C E It is recommended to perform one preventive maintenance per year.
Page 28 Minimum operating temperature with -30ºC Low Temperature Kit Operating humidity 5% to 95% Non-condensing Equipment to be installed outdoor shall be provided with the Low Temperature Kit in order to comply with the IEC 61851-1:2017 CIRCONTROL — eVolve Series — Installation Manual...
Page 29 PROTECTIONS Miniature Circuit Breaker (MCB) Overcurrent protection IEC 60898-1 (Curve C) RCD Type A (30 mA) + 6 mA Residual current protection RCD Type B (Optional) MODEL SPECIFICATIONS Display LCD Multi-language ISO/IEC 14443 A&B RFID reader Felica ISO/IEC 15693/ICODE Meter MID Class 1 - EN50470-1/3 Ethernet 10/100BaseTX (TCP-IP)
Page 30 Minimum operating temperature with -30ºC Low Temperature Kit Operating humidity 5% to 95% Non-condensing Equipment to be installed outdoor shall be provided with the Low Temperature Kit in order to comply with the IEC 61851-1:2017 CIRCONTROL — eVolve Series — Installation Manual...
Page 31 PROTECTIONS Miniature Circuit Breaker (MCB) Overcurrent protection IEC 60898-1 (Curve C) RCD Type B Residual current protection MODEL SPECIFICATIONS Display LCD Multi-language ISO/IEC 14443 A&B RFID reader Felica ISO/IEC 15693/ICODE Meter MID Class 1 - EN50470-1/3 Ethernet 10/100BaseTX (TCP-IP) Wi-Fi Wi-Fi 2.4 GHz (IEEE 802.11 b/g/n) Interface protocol OCPP 1.6J / 2.0.1 Ready...
Page 32 Frequency 50 Hz / 60 Hz This is the cable cross section recommended by Circontrol for the maximum AC input current. However, the final cross section must be calculated by a qualified technician taking into account the specific conditions of installation and the local regulations.
Page 33 PROTECTIONS Miniature Circuit Breaker (MCB) Overcurrent protection IEC 60898-1 (Curve C) RCD Type A (30 mA) + 6 mA Residual current protection RCD Type B (Optional) MODEL SPECIFICATIONS Display Touch screen 8” ISO/IEC 14443 A&B MIFARE Classic/Desfire EV1 RFID reader ISO 18092 / ECMA-340 NFC 13.56 MHz Meter...
Page 34 Need help? CIRCONTROL — eVolve Series — Installation Manual...
Page 35 In case of any query or if further information is required, please contact our Post-Sales Department. support@circontrol.com www.circontrol.com (+34) 937 362 940 (+34) 937 362 941...
