Wallbox eVolve Series - Installation Manual
5
Installation Kit:
10
2x
Wall plates
•
Screws and plastic anchors are NOT INCLUDED.
•
The installation kit has been tested on a concrete wall. For the unit
to be securely fixed in such conditions, it is recommended to use:
8 x Inox A2 wall screws: DIN 7982 Ø4,8x38 or DIN 7981 Ø4,8x38
8 x plastic anchors: 6x30
•
If the installation surface has different properties, the screws and
plastic anchors must be defined by a qualified installer.
1x
Fixation Screw
