18 Maintenance and Inspection
18.1 Maintenance Parts
18.1.4

Graphite ferrule

Graphite ferrule G0.5 (with 10 pcs)
Graphite ferrule G0.8 (with 10 pcs)
18.1.5

Capillary column

To select a capillary column, refer to a column manufactuer's catarog.
18.1.6

Flow controller

Molecular sieve filter
Trap (SPLIT)
Trap (PURGE)
Aluminum gaskets
18.1.7

Hydrogen flame ionization detector (FID)

Jet
Jet, φ0.8
FID Collector
Igniter
18.1.8

Miscellaneous

FPD detector
FTD detector
GC-2010 Plus
286
Part name
Part name
Part name
Part
Filter (S)
Filter (P)
Filter (Sn)
Quartz cylinder
FTD collector ASSY
FTD-2010 collector repair kit
P/N
221-32126-05 Capillary column installation
(less than 0.5 mm o.d.)
221-32126-08 Wide bore carillary column installation
(0.5 mm to 0.8 mm o.d.)
P/N
221-34121-94 For removing contamination in carrier
gas
221-42559-92 Split flow line trap
221-42559-92 Septum purge flow line trap
201-35183 For tubing connections
P/N
221-48258-91 Standard Jet for FID, 0.3 mm inner
diameter
221-49373-91 For water analysis, 0.8 mm inner diameter
221-72322-91
221-41847-93 Igniter for FID
Name
Purpose
Purpose
Purpose
P/N
221-73354-01
221-73354-02
221-73354-03
221-46552
221-45586-91
221-49079-91
