5 Basic Key Operation
5.1 Keypad Description and Operation
5.1.1

Keypad operation

The keypad is used to operate the system and make parameter settings. The table below
shows the function of each key.
Name
START key
STOP key
DIAG key
SYSTEM key
PF key
Toggle key
MONIT key
SET key
FUNC key
COL key
FLOW key
INJ key
DET key
OPTION key
HELP key
Cursor key
[ △ ], [ ▽ ], [ ] and [
Numeric keys
[0] ~ [9]
Clear key
[CE] key
ENTER key
GC-2010 Plus
54
Starts the temperature program, pressure/flow rate program and time program.
If a Pre-Run program is set, the Pre-Run program starts.
Stops the program.
Performs unit self-diagnosis.
Also, used for maintenance functions such as confirmation of various logs, part
replacement status, and standard signal out put.
Starts/stops GC.
Manages the analytical condition file.
Selects the PF menu displayed at bottom of the screen.
(PF = programmable function)
Toggles through the PF menu displayed at bottom of the screen.
Monitors the GC status and analysis status.
Displays the GC temperature, pressure and flow rate status for each heated zone,
as well as chromatograms.
Accesses commonly-used items, such as temperature, pressure and flow rate for
each component on one screen.
Manages the analytical condition file like the [SYSTEM] key.
Accesses less frequently used items.
Sets the oven temperature program.
Sets the carrier gas flow rate parameters, such as pressure, flow rate and split
ratio.
Sets the temperature of injection port (or temperature program for an OCI/PTV).
Sets the detector temperature, range and current or other detector-related param-
eters.
Sets the parameters for optional units, such as an auto injector or CRG.
Describes the procedure and sugggests valid parameter ranges.
Jumps to a desired item using an index function.
Moves cursor up, down, left and right.
A blinking cursor indicates the location of parameter value entry.
]
[ ] and [ ] keys may be used to change the selection.
Enter numeric values.
・ Clears the current numeric value.
・ Clears display and alarm during an error.
Validates parameter input or item selection.
Function
