14.2.5

Parameter log

When "3. PARAMETER LOG" is selected, parameter names and new values are
displayed when parameters are changed. In addition, the direct operation of valves, etc.
are also displayed.
(1) Screen description
Select "2. LOG READING MENU" from the [DIAG] key main screen, then select "3.
PARAMETER LOG". The screen shown in Fig. 14.2.5 appears.
Up to 50 logs are saved. If the number of logs exceeds 50, existing logs are deleted
starting from the oldest.
NOTE If there are more items than can be displayed on one screen, scroll through the screen using the left
and right arrow keys.
(2) PF menu
PF menu
Deletes all displayed logs.
When [Clear Log] (PF menu) is pressed, the screen changes and the
Clear Log
message "Clear log with PF2" appears. Press [Clear Log] (PF menu) to
clear the log.
Print Prints the parameter log to a Chromatopac.
Fig. 14.2.5 Parameter log screen
Description
14 Diagnosis
14.2 Log Reading Menu
Reference
section
――
――
