User Manual
PT-IP-HD26X
3. Specification
Technical
HDMI Compliance
HDCP Compliance
Video Bandwidth
Video Compression
Standard
Transmission Distance
Video Resolution
Color Space
Color Depth
Audio Formats
Connection
Encoder
Decoder
Mechanical
Housing
Color
Dimensions
Weight
Power Supply
Power Consumption
Operating Temperature
Storage Temperature
Relative Humidity
HDMI 1.3
HDCP 1.4
4.95Gbps
H.265/H.264
100m (CAT5E/6/6A/7)
Up to 1920x1200@60Hz 4:4:4
RGB4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
Input: 8-bit, 10-bit, 12-bit (1080p@60Hz);
Output: 8-bit
LPCM 2.0CH (32/44.1/48KHz)
1x HDMI IN [Type A, 19-pin female]
1x LAN [RJ45 connector, POE]
1x AUDIO IN/OUT [3-pin phoenix connector]
1x RS-232 [3-pin phoenix connector]
1x HDMI OUT [Type A, 19-pin female]
1x LAN [RJ45 connector, POE]
1x AUDIO OUT [3-pin phoenix connector]
1x RS-232 [3-pin phoenix connector]
Metal enclosure
Black
Encoder / Decoder: 120mm [W] x 95mm [D] x 21.5mm [H]
Encoder: 74g, Decoder: 74g
Input: AC100 - 240V 50/60Hz,
Output: DC 12V/1A
Encoder: 2.88W, Decoder: 2.88W
14 - 113°F / -10 - 45°C
-4 - 140°F / -20 - 60°C
20 - 90% RH (no condensing)
10
