PT-C-DADM
3. Specification
Input Ports
Output Ports
Signal to Noise Ratio
Degree of Separation
Frequency Response
Dimensions
Weight
4. System Diagram
The following diagrams illustrate typical input and output
connections that can be utilized with this decoder:
1. Connect a source (e.g. Blu-Ray Player, game console, A/V Receiver,
etc.) to the audio Decoder's SPDIF input port by fiber cable or
Coaxial input port by coaxial cable.
2. Connect a headphone or analog audio amplifier to the audio
output port on the Decoder.
3. Power on the Decoder and select the switch to your need audio
input port.
1 x Optical (Toslink), 1 x Digital Coaxial
1 x RCA (L/R), 1 x 3.5mm (Headphone)
103db
95db
(20Hz ~ 20KHz) +/- 0.5db
78mm(D)x60mm(W)x22mm(H)
102g
