User Manual
PT-PSW-41RS
5. Specification
I/O Connections
HDM Input
DP Input
DVI Input
VGA Input
External Audio Input
HDBaseT Output
Audio Output
IR Input
RS232 Control
External button Control (SIG
5V)
Button Control(Front Panel)
PoH Mode Switcher
Firmware Update
DC 12V Power
Video Performance
DVI/VGA Scaling
Resolutions
Maximum Pixel Clock
Bandwidth
HDMI Compliance
One(1) Type A receptacle
One(1) Type A DisplayPort
One(1) Type DVI-I female receptacle
One(1) HD-15 female receptacle
One(1) 3.5mm TRS jack
One(1) RJ45 receptacle
One(1) 3-pin phoenix connector
One(1) 3.5mm TRS jack
One(1) DB9 female receptacle
One(1) 3-pin phoenix connector
One(1) button in total
One(1) 2-position slider switch
One(1) USB receptacle
One(1) Locking Barrel(5.5mm outside diameter,
2.1mm inside diameter)
1920x1200@60Hz, 1920x1080@60Hz, 1600x1200，
1360x768@60Hz, 1280x800@60Hz,
1280x720@60Hz, 1024x768@60Hz.
340MHz
HDMI:10.2Gbps(3.4Gbps per color)
C-Video:150MHz
YPbPr: 170MHz
VGA: 375MHz
HDMI1.4, HDCP2.2
22
