Notes:
(1) For the default IP mode of Control LAN port of the Controller Box is DHCP, the PC also
needs to be set to "Obtain an IP address automatically" mode, and a DHCP server (e.g.
network router) is required in the system.
(2) If there is no DHCP server in the system, 192.168.0.225 will be used as the IP address
of Control LAN port. You need to set the IP address of the PC to be in the same network
segment. For example, set PC's IP address as 192.168.0.88.
(3) You can access the Web GUI by inputting Control LAN port IP address
(192.168.0.225) or URL "http://controller.local" on your computer's browser.
(4) No need to care about settings of Video LAN port of the Controller Box, they are
managed by Controller automatically.
(5) When the Network Switch does not support PoE, the Encoder, Decoder and Controller
Box should be powered by DC power adpater.

5. Switch Model

A network Switch used to set up the system should support below features:
1. Type of layer 3/managed network Switch.
2. Gigabit bandwidth.
3. Support multicast, and need to enable the multicast function.
4. Support IGMP snooping, and need to enable the IGMP snooping function.
5. Support filter/drop unregistered Multicast traffic, and need to enable the function.
The following Switch models are highly recommended.
Manufacturer
HUAWEI
NETGEAR
6. IP System Control
This product can be controlled by Controller Box or third-party controller.
For details of IP system control, and to understand the more advanced features of the
PT-IP-HD26X series, please refer PT-IP-CNTRL10 product information.
Model Number
S5720S-28X-PWR-LI-AC
S3300
