PureTools PT-IP-HD26X User Manual page 8

User Manual
PT-IP-HD26X
No. Name
POWER LED
1
(Red)
LINK LED
2
(Green)
3 LED screen
4 CH SELECT
5 RESET
6 RS-232
7 AUDIO IN/OUT
8 LAN (POE)
Link Signal
9
Indicator
(Green)
Description
The LED flashes at 1 Hz during the system startup, and the
LED is always on after the startup is complete.
Network connection status LED.
▪ Light on: Network is connected, and there is compatible
signal (with a resolution of less than 1920*1200, and the
frame rate is less than or equal to 60) .
▪ Light flashes at 1Hz: Network is connected, but there is no
video input.
▪ Light flashes at 10Hz: Network is connected, but the signal
is incompatible (resolution is greater than 1920*1200, or
the frame rate is greater than 60).
▪ Light off: Network is not connected.
Displays IP address, ID etc information.
Note: When clicking the SHOW ME option of the
corresponding machine on the Controller, the LED screen
of the corresponding machine will flash "SHO", so that you
can find the corresponding machine in the system.
Used to set Encoder ID and other settings.
System reset button. Press and hold this button for 5
seconds, the system will restart and restore factory Settings.
RS-232 serial port, supporting signal pass-through and local
serial port control.
AUDIO IN: Analog stereo audio input port. Connect to an
audio input source device.
AUDIO OUT: Analog stereo audio output port. Connect to an
audio output device.
100M/1G Network port. Connect to a Switch/Router/Hub for
data transmission or POE function.
▪ Illuminated: The network cable is connected normally.
▪ Dark: The network cable is not connected well.
