Decoder Panel - PureTools PT-IP-HD26X User Manual

User Manual
PT-IP-HD26X

2.2 Decoder Panel

1
POWER
DC 12V
12
No. Name
POWER LED
1
(Red)
LINK LED
2
(Green)
3 LED screen
4 CH SELECT
5
RESET
6 RS-232
3
2
LINK
HDMI OUT
10
11
Description
The LED flashes at 1 Hz during the system startup, and the
LED is always on after the startup is complete.
Network connection status LED.
▪ Light on: Network is connected, and there is video data.
▪ Light flashes: Network is connected, but there is no video data.
▪ Light off: Network is not connected.
Displays IP address, ID etc information.
Note: When clicking the SHOW ME option of the
corresponding machine on the Controller, the LED screen of
the corresponding machine will flash "SHO", so that you can
find the corresponding machine in the system.
Used to set Decoder ID and other settings.
System reset button. Press and hold this button for 5
seconds, the system will restart and restore factory Settings.
RS-232 serial port, supporting signal pass-through and local
serial port control.
4
CH SELECT
L R
AUDIO OUT
8
9
7
7
5
D EC
RESET
RS-232
6
